Ceramtec
Sapphire
Specifications
Housing:
52 Nickel Iron
Optic:
Sapphire
Magnetic materials:
Yes
Transmission range (80% Min):
0.25 to 4 Microns
Temperature Range:
-269º C to 450º C, ISO KF -25º C to 205º C
Pressure @ 20ºC:
.55 View Dia.: 400 PSIG (27.6 Bar)
.94 View Dia.: 160 PSIG (11 Bar)
1.94 View Dia.: 50 PSIG (3.4 Bar)
Leak Rate:
<1x10-10 atm-cc/sec (He)
PDF Downloads
| 17105-01-W | VIEWPORT SAPPHIRE | .55 (14) | Weld | Yes |
0 in stock
$249.48
|
Enquire | |
| 17105-02-W | VIEWPORT SAPPHIRE | .94 (24) | Weld | Yes |
0 in stock
$308.88
|
Enquire | |
| 17105-03-W | VIEWPORT SAPPHIRE | 1.94 (49) | Weld | Yes |
0 in stock
$819.72
|
Enquire | |
| 17106-01-KF | VIEWPORT SAPPHIRE | .55 (14) | NW16KF | Yes |
0 in stock
$328.68
|
Enquire | |
| 17106-02-KF | VIEWPORT SAPPHIRE | .94 (24) | NW40KF | Yes |
0 in stock
$380.16
|
Enquire | |
| 18617-01-CF | VIEWPORT SAPPHIRE | .94 (24) | NW35CF | Yes |
0 in stock
$394.68
|
Enquire | |
| 18617-02-CF | VIEWPORT SAPPHIRE | 1.94 (49) | NW63CF | Yes |
0 in stock
$1,112.76
|
Enquire | |
| 9547-04-CF | VIEWPORT SAPPHIRE | .55 (14) | NW16CF | Yes |
0 in stock
$302.28
|
Enquire |
