Latest Products from CeramTec

Discover the latest products from CeramTec, offering advanced ceramics and Ceramaseal® hermetic component solutions.

High Density Sub-Ds

Compared to a Standard Sub-D, High Density Sub-Ds have:

• Lower voltage rating: 375V DC
• Lower current rating: 2 Amps/pin
• Same temperature range: -269C to 450C
• Same pressure at 20°C: 1350 PSIG (15 Pin)
• Different pin diameter: .030" [0.76mm]
• Different pin counts: 15, 26, 44, 62, 78

Push-Pull Connectors

Some advantages of the push-pull coaxial connectors are:

• Ideal for applications which require frequent plug removal
• Very simple, safe plug connectivity and disconnecting
• Flexible design - comes in all standard flanges and weldable configurations

Sub-Cs

Sub-Cs are higher density multi-pin connectors with plugs in smaller flanges (1.33”CF), essentially providing all the capability of a Sub-D in a smaller version.

Power Boots

The new and improved power boots offer the following benefits:

• Lower lead times - this has come down from 20+ weeks to less than 6 weeks if not in stock
• Custom lengths are available
• Lower costs

Updated Mil-C-26482s

The original design for Mil-C-26482 Connectors had a single glass-ceramic perform for all pins which would produce inconsistent results when sealing. However, in the new design:

• Each pin has its own small preform which has led to very consistent results
• It's easy to plan deliveries accurately
• All ratings are identical, parts have been fully tested and perform the same if not better on all ratings

Updated Spade Type Thermocouples

The Spade style contacts and air-side thermocouple plugs that CeramTec has historically used on Thermocouples have been discontinued.

CeramTec has found a replacement manufacturer for the spade contacts and plugs, which they consider a direct replacement – the components are interchangeable.

All thermocouple feedthrough part numbers will remain the same, but the replacement plug numbers will change from 8151-XX to 25735-XX.

High Power Mil-C-5015 Connectors & Power Ds

A high powered multi-pin connector in a small footprint, this product offers:

• Standard air-side connectivity (Mil-C-5015)
• Simplified Sub-C style Vacuum side Connectivity
• Copper-cored pins for higher current carrying capabilities (up to 20 Amps)
• Glass-ceramic Seals for simplified design & high pressure capabilities
• 3, 4, 6, 10, 20 & 35 pin versions

View the full range of CeramTec products or get in touch with the Testbourne team to find out more.
