17142-01-W ISOLATOR VACUUM 6.0 (152) 30kV Weld 40 2.7 Yes
0 in stock
$2,313.96
Enquire
17142-02-W ISOLATOR VACUUM 6.0 (152) 55kV Weld 40 2.7 Yes
0 in stock
$2,905.32
Enquire
17142-03-W ISOLATOR VACUUM 6.0 (152) 75kV Weld 40 2.7 Yes
0 in stock
$2,785.20
Enquire
17146-01-CF ISOLATOR VACUUM 6.0 (152) 30kV NW150CF 40 2.7 Yes
0 in stock
$3,274.92
Enquire
17146-02-CF ISOLATOR VACUUM 6.0 (152) 55kV NW150CF 40 2.7 Yes
0 in stock
$3,866.28
Enquire
17146-03-CF ISOLATOR VACUUM 6.0 (152) 75kV NW150CF 40 2.7 Yes
0 in stock
$3,545.52
Enquire
Specifications
Tube: 52 Nickel Iron
Insulation: Alumina ceramic
Magnetic materials: Yes
Voltage Rating: See table
Temperature Range: -269º C to 450º C
Pressure @ 20ºC: 40 PSIG (2.7 Bar)
Leak Rate: <1x10-10 atm-cc/sec (He)
Data sheet
